Arisaka Defense Magnifier Low Mount for EOTech Magnifier
Product information "Arisaka Defense Magnifier Low Mount for EOTech Magnifier"
The Arisaka Low Magnifier Mount positions EOTech magnifiers at a 22,9mm/0.9" optic centerline over the rail. This optic height is useful on rifles with a large drop from the top receiver rail to the comb of the stock, such as the AK family and derivatives, HK G3 and MP5 and clones, Sig 551/552/553, and B&T APC series.
The Arisaka Low Magnifier Mount uses a unique pivot system which stays securely in place, yet is easy to rotate outwards 90 or 180 degrees. The 180 degree position places the optic well below your view plane, increasing peripheral vision, and providing an unobstructed view for the non-dominant eye of left handed shooters.
The Low Magnifier Mount matches up perfectly with the Arisaka Low Aimpoint Micro Mount, providing a complete magnified red dot solution. The Low Magnifier Mount is also compatible with several other low mounts, such as the Aimpoint 12436 and 12738 standard mounts and Aimpoint 12905 LRP, but the red dot and magnifier may not be perfectly in-line.
The clamping ring diameter is 30mm, allowing use with the Aimpoint 3X-C, 3XMAG, 3XMAG-1, and 6XMAG-1.
Weight without magnifier: 74g
Optic Centerline: 22,9mm/0.9" with Aimpoint Micro T1/T2
Each mount is CNC machined from 6061-T651 and 7075-T651 aluminum and MIL-A-8625 Type III hard coat black anodized.
Recommended torque values:
Picatinny clamp - 5.7nm
EOTech Mounting Screws - 2,3nm
Made in the USA.
